Branching swimlane plot for observed paths and counterfactual predictions

geom_kodom_branch.Rd

Draws one horizontal path per subject for the observed trajectory, then fans out into sub-lanes — one per medication or intervention arm — for predicted (counterfactual) trajectories. The branching time may differ across subjects.

Usage

geom_kodom_branch(
  mapping = NULL,
  data = NULL,
  stat = StatKodomBranch,
  position = "identity",
  ...,
  sort_by = "none",
  n_max = Inf,
  lane_width = 1,
  branch_fraction = 0.7,
  show_points = TRUE,
  show_fork = TRUE,
  na.rm = FALSE,
  show.legend = NA,
  inherit.aes = TRUE
)

Arguments

mapping

Set of aesthetic mappings created by ggplot2::aes().

data

A data frame. If NULL, inherits from the plot.

stat

The stat to use. Defaults to StatKodomLine.

position

Position adjustment, almost always "identity".

...

Other arguments passed to ggplot2::layer().

sort_by

Lane ordering. One of "none" (default), "mean", "mean_asc", "first", "last" — all refer to the colour variable.

n_max

Maximum number of subjects to display. A random sample is taken when exceeded. Default Inf (all subjects).

lane_width

Positive numeric. Vertical distance between adjacent subject lanes. Default 1.

branch_fraction

Fraction of lane_width devoted to prediction sub-lanes. Default 0.7. With K arms the sub-lane step is branch_fraction / K.

show_points

If TRUE (default), draws a point at every observation. Set to FALSE, or map shape = NA / size = 0, to suppress points.

show_fork

Logical. If TRUE (default), draws a vertical fork connector at each subject's branch point.

na.rm

If TRUE, silently remove rows with missing required aesthetics.

show.legend

Logical. Should this layer appear in the legend?

inherit.aes

If FALSE, overrides the default aesthetics.

Value

A ggplot2 layer object.

Details

Data format. Supply NA in the medication column for all observed rows (pre- and post-branch). Supply a non-NA arm label (e.g. "DrugA") for every predicted row. The stat replaces NA with "observed" in its output so that the linetype scale receives a clean string for every row.

Linetype. Map linetype = <arm_column> in aes() and supply a scale_linetype_manual() so that the legend appears and the linetypes are exactly what you want. The stat converts NA (observed rows) to the string "observed" before the scale is applied, so target that key explicitly:

aes(linetype = arm, medication = arm)   # both point to the same column
scale_linetype_manual(
  values = c("observed" = "solid", "DrugA" = "dashed", "DrugB" = "dotted")
)

Fork connector. A short vertical segment is drawn at each subject's branch point (the first x that appears in a predicted arm), connecting the observed lane to the topmost arm. Suppress with show_fork = FALSE.

Lane layout. Each subject occupies a primary band of width lane_width. Within that band the observed path is at the base; each prediction arm sits at an equal sub-lane fraction above it controlled by branch_fraction. With two arms and branch_fraction = 0.7, arm 1 is at 0.35 * lane_width above the base and arm 2 is at 0.70 * lane_width, leaving 30% clearance before the next subject.

Y-axis labels. Subject IDs can be added by setting custom breaks:

scale_y_continuous(
  breaks = seq_len(n_subjects) * lane_width,
  labels = subject_ids
)

Aesthetics

  • x — time (numeric or Date)

  • id — subject identifier; determines the primary lane position

  • colour — measured value mapped to colour (interpolated along path)

  • medication — NA for observed rows; a character/factor arm label for predicted rows. Each unique non-NA value becomes one sub-lane.

  • size, linewidth, alpha, shape, stroke — standard path/point aesthetics. linetype is set by the stat (medication name / "observed").

Examples

# \donttest{
library(ggplot2)
df <- data.frame(
  subject_id = rep(1:5, each = 4),
  time = rep(1:4, 5),
  visit_month = rep(1:4, 5),
  value = rep(1:4, 5),
  hba1c = rep(1:4, 5),
  arm = rep(c("Treatment", "Control"), c(12, 8))
)
ggplot(df, aes(
  x = time, id = subject_id,
  colour = hba1c, linetype = arm, medication = arm
)) +
  geom_kodom_branch(sort_by = "mean", lane_width = 2) +
  scale_linetype_manual(
    values = c("observed" = "solid", "DrugA" = "dashed", "DrugB" = "dotted")
  ) +
  scale_colour_kodom() +
  theme_kodom()
#> Warning: No shared levels found between `names(values)` of the manual scale and the
#> data's linetype values.
#> Warning: No shared levels found between `names(values)` of the manual scale and the
#> data's linetype values.
#> Warning: Removed 20 rows containing missing values or values outside the scale range
#> (`geom_kodom_branch()`).

# }
